Increased Rate Racing Pressure regulator - Ethanol E85 compatible

Increased Rate Racing Pressure regulator

Replacing the standard fuel pressure regulator with an adjustable model can easily improve the performance of the standard injection system by eliminating throttle dips.
The installation of a pressure regulator can also be a cost-effective alternative when converting to Ethanol E85.

It can be installed in a bypass position between the pump and the injection rail, in which case three connectors are required.
It can also be installed in a standard position on the fuel return line, in which case one of the two ports can be plugged or connected to a pressure gauge.

Technical specifications :
Engines: Atmospheric or turbocharged
Air/fuel ratio: 1:1.7
Compatible with E85.
2 JIC6 connections
1 1/8" NPT connection
1 5mm tail connector mounted on 6x1mm thread

Base pressure adjustable from 1 to 8 bar (a suitable fuel pump is required).
Supplied with 2 connectors (1/8" NPT to 8 mm) + 1 blanking plug 1/8" NPT.

This regulator is manufactured with a special alloy. Each component is assembled by hand before being tested to ensure perfect operation.
